500M 8W Analog FPV VTX Drone Wireless Video Transmitter and Receiver 8 Channels

500M 8W Analog FPV VTX Drone Wireless Video Transmitter and Receiver 8 Channels

Product Details:
Place of Origin: China
Brand Name: Kimpok
Certification: CE
Model Number: KP-500VTX8W
Detail Information
Place of Origin:
China
Brand Name:
Kimpok
Certification:
CE
Model Number:
KP-500VTX8W
Type:
Wireless Video Transmission
Frequency:
500Mhz
Transmit Power:
8W
Channel:
8 Channels
Private Mold:
Yes
Port:
Shenzhen
Distance:
Up To 60km LOS From Air To Ground
Antenna Interface:
MMCX
Shell Material:
Aluminum
Voltage:
DC10-36V
Trading Information
Minimum Order Quantity:
1 Piece
Price:
Negotiation
Packaging Details:
International standard packing
Delivery Time:
1-3 working days
Payment Terms:
T/T, PayPal, Alipay
Supply Ability:
5000 piece/month
Product Description

500M 8W Analog FPV VTX Drone Wireless Video Transmitter and Receiver 8 Channels



Description:



This is a cutting-edge wireless video transmission device that utilizes fm modulation technology and operates on a newly developed frequency band.By steering clear of the commonly used standard frequencies of 1.2 ghz, 1.5 ghz, and 2.4 ghz, this device is designed to be effective in the interference may be issue in complex environments.



The receiver sensitivity is impressive at -85 dbm, ensuring that the transmitted images remain both clear and stable in challenging conditions.Equipped with a high-gain antenna, this device can achieve the transmission range of 10 to 15 km, where the obstacles may affect signal strength.Remarkably, when deployed in open area or in an air-to-ground line of sight (los) scenario, the transmission distance can extend up to 100 km, depending on the specific conditions of the work environment.



VTX Specification:



Product name Analog video transmitter
Voltage Dc 10v~36v
Current 1.6a
Modulation Fm
Frequency 500mhz
Channels 8 channels
Frequency band 460mhz, 490mhz, 500mhz, 520mhz, 540mhz, 560mhz, 580mhz, 600mhz
Transmit power 8 watt
Video output 1 vp-p (fm)
Temperature -10℃ ~ +50℃
Antenna port Sma female
Transmitter weight 104g
Dimensions 98*55*18mm (without antenna)




VRX Specification:



Product Analog video receiver
Voltage Dc 10v~18v
Receiving sensitivity -85db
Modulation Fm
Frequency 300mhz~900mhz(optional)
Channels 8 channels
Frequency band 490mhz, 500mhz, 520mhz, 540mhz, 560mhz, 580mhz, 600mhz, 620mhz
Video output 1 vp-p (fm)
Temperature -10℃ ~ +50℃
Antenna port Sma female
Transmitter weight 83g
Dimensions (l * w * h) 75*45*20mm (antenna port not included)
