| Place of Origin: | Guangdong, China |
| Brand Name: | KimpoK |
| Certification: | CE |
| Model Number: | KP-300VTX2W |
300Mhz 2W VTX Transmitter 300M Receiver VRX for FPV Racing Drone 12~36V
Low frequency Description:
This is a fire-new wireless video transmission equipment, which adopts FM modulation mode and brand-new frequency, avoiding the standard frequency of 1.2Ghz/1.5Ghz/2.4Ghz wireless transmission that has been used more in the same range, and is more suitable for use in complex environments. The sensitivity of the receiver is -85dBm, and the transmitted image is clear and stable. With ground high gain antenna, it can transmit 1~2km in the open area of the city, and about 20km in the air-to-ground LOS with high gain antenna (Note: the transmission distance is different in different environments, and the specific transmission distance depends on the actual working environment).
VTX Specification:
|
Product name |
Analog video transmitter |
|
Voltage |
DC 12V |
|
Current |
600mA |
|
Modulation |
FM |
|
Frequency |
300Mhz |
|
Channels |
8 channels |
|
Frequency band |
320Mhz, 340Mhz, 360Mhz, 380Mhz (customization) |
|
Transmit Power |
2 watt |
|
Video Output |
1 Vp-p(FM) |
|
Temperature |
-10℃ ~ +50℃ |
|
Antenna port |
SMA female |
|
Transmitter Weight |
83g |
|
Dimensions |
64*46*20mm (antenna port not included) |
VRX Specification:
|
Product |
Analog video receiver |
|
Voltage |
DC 12V |
|
Receiving sensitivity |
-85dBm |
|
Modulation |
FM |
|
Frequency |
300Mhz |
|
Channels |
8 channels |
|
Frequency band |
320Mhz, 340Mhz, 360Mhz, 380Mhz (customization) |
|
Video Output |
1 Vp-p(FM) |
|
Temperature |
-10℃ ~ +50℃ |
|
Antenna port |
SMA female |
|
Transmitter Weight |
83g |
|
Dimensions |
83*68*15mm (antenna port not included) |
