| Place of Origin: | Guangdong, China |
| Brand Name: | Kimpok technology |
| Certification: | CE |
| Model Number: | KP-15VTX5W |
60km 1.5Ghz 5W UAV FPV VTX Drone Video Transmimtter 8 Channels 36V
1.5G 5W VTX Description:
The new wireless video transmission device you described utilizes FM modulation mode and operates on a brand-new frequency range, steering clear of the commonly used 1405~1680MHz spectrum. This approach enhances its suitability for deployment in complex environments where traditional frequencies might face interference.
Key features of this device include:
It's important to note that the actual transmission distance can vary depending on the specific working environment. The device's capabilities allow for reliable video transmission over significant distances, making it suitable for various applications that require long-range wireless video communication.
1.5Ghz VTX Specification:
|
Product name |
Analog video transmitter |
|
Voltage |
DC 10V~36V |
|
Current |
1.6A |
|
Modulation |
FM |
|
Frequency |
1.5Ghz |
|
Channels |
8 channels |
|
Frequency band |
1460Mhz, 1480Mhz, 1500Mhz, 1520Mhz, 1540Mhz, 1560Mhz, 1580Mhz, 1600Mhz |
|
Transmit Power |
5 watt |
|
Video Output |
1 Vp-p(FM) |
|
Temperature |
-10℃ ~ +50℃ |
|
Antenna port |
SMA female |
|
Transmitter Weight |
104g |
|
Dimensions |
98*55*18mm (without antenna) |
VRX Specification:
|
Product |
Analog video receiver |
|
Voltage |
DC 10V~18V |
|
Receiving sensitivity |
-85dB |
|
Modulation |
FM |
|
Frequency |
1Ghz |
|
Channels |
8 channels |
|
Frequency band |
1460Mhz, 1480Mhz, 1500Mhz, 1520Mhz, 1540Mhz, 1560Mhz, 1580Mhz, 1600Mhz |
|
Video Output |
1 Vp-p(FM) |
|
Temperature |
-10℃ ~ +50℃ |
|
Antenna port |
SMA female |
|
Transmitter Weight |
83g |
|
Dimensions (L * W * H) |
65*46*20mm (antenna port not included) |
Q1: What can I buy from you?
COFDM digital AV transmitter, IP mesh radio, analog video transmitter, radio data transceiver, and transmitter receiver OEM main board.
Q2: Why should I choose you?
Our core R&D team comes from the first-class university in China, major in communication engineering. We believe that wireless communication will keep on developing in professional markets in the future.
Q3: Do you have a minimum order quantity?
No MOQ limit, 1pc is acceptable.
Q4: What kind of product service can I have?
OEM & ODM service.
Q5: What is the product warranty?
We offer two-year-warranty and lifelong maintenance.
Q6: What is the average lead time?
5-7 working days for regular model, and 20-30 working days for customized model.
Q7: What kinds of payment methods do you accept?
We accept bank transfer, Western Union, PayPal, or cash payment.
Q8: Can you supply the relevant documentation?
Yes, we can provide most documentation including Certificates of Analysis / Conformance; Country of Origin, and other export documents where required.
Our Service:
· One-stop ODM/OEM solution;
· 24-hour technical support;
· Lifelong maintenance (Replacement parts will be charged after a year);
· Provide professional system design and construction;
· You will get good price and high quality here since we are an experienced manufacturer in wireless microwave transmission area since 2008, we are the source.
